热管理产品组合 - 软管线 EHW194 EPDM橡胶软管：UL94 V0 额定软管
EHW194软管符合 UL94 V0防火等级 ，有效保障特殊情况下数据中心的安全运行
Thermal Management Portfolio – Hose line EHW194: UL94 V0 Rated Hose
数据中心和电动汽车充电器中的液体冷却应用EPDM软管

设计为液冷而生 过氧化物固化的 EPDM 合成橡胶软管
数据中心用防火阻燃液冷EPDM橡胶软管-UL94 V0认证
Boston by Danfoss Royal EHW194 Water Liquid Cooling Hose
Tube Peroxide-cured Synthetic EPDM Rubber

丹佛斯EHW194软管符合 UL94 V0防火等级 ，有效保障特殊情况下数据中心的安全运行。 材质是EPDM,多种颜色可供选择.Engineered to keep you cool 液体冷却是一种使用水作为冷却介质的创新技术，有助于在数据中心应用中保持较低的计算机处理器温度。Boston by Danfoss Royal在设计时就考虑到了这项新兴技术。EHW194 软管符合 UL 94 V-0 等级，具有卓越的柔韧性和抗扭结性，设计用于在狭小空间内使用，以简化安装和维护。EHW194 提供多种尺寸和颜色，并配有经认证的丹佛斯接头 — 我们让您轻松进入这个新市场。Danfoss Power Solutions, a leading global supplier of mobile and industrial hydraulics as well as electric powertrain systems, has launched two new hose solutions specifically for liquid cooling applications. Boston by Danfoss Emperor EHW094 TPU hose and Royal EHW194 EPDM hose offer superior performance and high flexibility for electric vehicles, data centers, and other liquid cooling needs.

数据中心用防火阻燃液冷EPDM橡胶软管-UL94 V0认证
Boston by Danfoss Royal EHW194 Water Liquid Cooling Hose
Tube Peroxide-cured Synthetic EPDM Rubber

丹佛斯EHW194 过氧化物固化的 EPDM 合成橡胶软管

1、EPDM管外层，棉线编织加强层
2、符合UL94 V0等级
3、多种颜色可以提供
4、工作温度: -40℃ to +125℃（-40℉ to 257℉）
5、规格：-04, -06, -08, -10 -12, -16

Features特征

- UL 94 V-0防火阻燃认证
- 防火罩
- 软管外表光滑 ，低CoF
- 多种颜色产品 ，红蓝色区分
- 具有扭转应变和抗扭折的柔性

EPDM橡胶
颜色: 黑色（BK）、蓝色（BU）、灰色（GY）、红色（RD）

工作温度: -40°C至+140°C（-40°F至+284°F）
认证：UL 94 V-0认证
包装：250 ft. reels

配套接头类型-Type of couplings
- 丹佛斯1G压接接头
- 丹佛斯100B无插座配件
- 丹佛斯快速断开

- 灵活的路由能力
- 多种颜色可供选择
- 专为伊顿无插座无压接接头解决方案而设计，具有出色的保持力
- 更大尺寸的产品，可结合到数据中心的内部机架和源线应用中
– 1 根软管用于整个系统

Boston by Danfoss Royal EHW194 Water Liquid Cooling

Liquid cooling is an innovative technique using water as a cooling medium to help keep computer processor temperatures low in data center applications. Danfoss designed Boston? Royal with this emerging technology in mind.

UL 94 V-0 rated and offering superior flexibility and kink resistance, this hose was designed to maneuver in tight spaces to simplify installation
and maintenance. Offered in a variety of sizes and colors, with approved Danfoss fittings—we have made it easy to emerge into this new market.

Features

- UL 94 V-0 rated
- Exceeds ASTM E84 Class 1/A Requirements
- Fire resistant cover
- Smooth-finish cover, low CoF
- Multiple color offerings
- Flexible with torsional strain and kink resistance

Order Fulfillment
- Made to Stock

Markets/Applications

- Data centers
- Electronic component cooling
- Telemedicine
- Cryptocurrency mining
- IT thermal management

Royal EHW194
Liquid cooling, using water as a solution, helps to eliminate the overheating of devices in data center applications
Boston by Danfoss, Roval EHW194-08 Water Liguid copling,12.7 MM (0,50 IN) DN12 UL94 VO 16 BAR (232 PSl with clamr
-40'c to 140°C (-40°F to 284°F)YYYYIMM/DD
Made in Türkiye 1/--/- XXXXX

Construction: Tube Peroxide-cured Synthetic EPDM Rubber
Reinforcement: 2 -ply textile
Cover Fire retardant Synthetic: EPDM Rubber
Colors Black (BK), Blue (BU),Grey (GY), Red (RD)
Operating Temperature: -40°C to +140°C (-40°F to +284°F)
Certications: UL 94 V-0 rated
Exceeds ASTM E84 Class 1/A Requirements
Packaging: 76.2 m (250 ft.) reels

Qualified with:
- Danfoss 1G crimp fittings
- Danfoss 100B socketless fittings
- Danfoss Hansen UQD quick disconnect coupling hose barb
- Danfoss Hansen FD83 quick disconnect coupling hose barb

- Aeroquip by Danfoss FC332 AQP Low Pressure SOCKETLESS Textile Braid Hose
- Boston by Danfoss Easy Couple H201 Air & Multipurpose Low Pressure
